Practice Free 300-815 Exam Online Questions
For s SIP to SIP call flow, when does Cisco Unified Border Element require transcoding resources for DTMF?
- A . interworking between an OOB method and RFC2833 for flow-around calls
- B . interworking between h245-signal and rtp-nte
- C . interworking between an OOB method and RFC2833 for flow-through calls
- D . interworking between h245-alpha numeric and sip-kpml
A
Explanation:
Reference: https://www.cisco.com/c/en/us/support/docs/unified-communications/unified-border-element/200412-DTMF-Relay-and-Interworking-on-CUBE.html#anc35
Cisco UCM has 100,000 entries in the database learned through the ILS Service. Parameter ILS Max Number of Learned Objects in Database value is set to 100,000.
What will happen to learned data when the service parameter value is reduced to 50,000?
- A . Cisco UCM does not write additional ILS learned objects to the database and will delete the first 50,000 entries learned to keep it to the service parameter value.
- B . Cisco UCM does not write additional ILS learned objects to the database and will delete the last 50,000 entries learned to keep it to the service parameter value.
- C . Cisco UCM does not write additional ILS learned objects to the database and keeps the existing database entries.
- D . Cisco UCM will overwrite an entry for newly learned data and keep the parameter value at 100,000.
Refer to the exhibit.
Users report that when they dial to Cisco Unity Connection from an external network, they cannot enter any digits.
Assuming only in-band DTMF is supported, what is a reason for this malfunction?
- A . The negotiated RTP port is outside of the range described by RFC, so inband DTMFs do not work.
- B . There is SIP Delayed Offer. DTMF is supported only in Early Offer.
- C . The rtpmap:0 value for the negotiated codec is marking DTMF as inactive.
- D . No DTMF is negotiated.
Refer to the exhibit.
A user reports that when they call a specific phone number, no one answers the call, but when they call from a mobile phone, the call is answered. The engineer troubleshooting the issue is expecting the far-end gateway to cut through audio on the 183 Session Progress SIP message.
Which SIP Profile configuration element is necessary for the Cisco Unified Communications Manager to send acknowledgement of provisional responses?
- A . Allow Passthrough of Configured Line Device Caller Information must be enabled.
- B . Accept Audio Codec Preferences in Received Offer must be set to On.
- C . On the SIP Profile, the configuration parameter SIP Rel1XX Options must be set to Send PRACK for all 1xx Messages.
- D . Early Offer for G Clear Calls must be enabled.
Which action is correct with respect to toll fraud prevention configuration in the Cisco Unified Communications Manager Express?
- A . Configure Direct Inward Dial for Incoming ISDN Calls with overlap dialing.
- B . Configure IP Address Trusted Authentication for Incoming VoIP Calls.
- C . Configure the command no ip address trusted authenticate under “voice service voip”.
- D . Enable Secondary Dial tone on Analog and Digital FXO Ports.
B
Explanation:
Reference: https://www.cisco.com/c/en/us/td/docs/voice_ip_comm/cucme/admin/configuration/manual/cmeadm/cmetoll.html#concept_ECC4F4E7ED0F45C594B703EEF34762F2
A collaboration engineer is configuring call pickup for a Cisco UCM user that currently has a working BLF speed dial button for the teammate’s extension. The user wants to see calls ringing on the teammate’s extension and to answer those calls by pressing the BLF speed dial button.
Which configuration step meets this requirement?
- A . Set the call pickup group to <none> for both extensions.
- B . Select the call pickup checkbox on the BLF speed dial settings.
- C . Assign both extensions to the same partition.
- D . Assign the extensions to different call pickup groups.
DRAG DROP
Drag and drop the commands from the bottom to the blanks in the code to implement a translation rule to allow only 11 digits to be received over a SIP trunk to a SIP provider. The Cisco UCM is currently sending calls to the Cisco Unified Border Element in E. 164 format. Not all options are used.
A company with only 15 users needs to have a phone system without deploying dedicated servers for this purpose.
Using the local Cisco router with Cisco UCME capabilities, which configuration is needed to support SIP phones?
- A . voice-register ephone
- B . ephone
- C . voice-register pool
- D . voice-register SIP
Refer to the exhibit.
Which INVITE is sent to 10.10.100.123 as a result of this log?
A)
B)
C)
D)
- A . Option A
- B . Option B
- C . Option C
- D . Option D
Alter a new SIP trunk is configured from a third-party SIP trunk provider, the call does not seem to work. A troubles hooting tool and a tiace log from the Cisco Unified Border Element shows that there is communication with the provider and that it is sending out SDP information in the 2XX response.
Why is the call not working?
- A . The Cisco Unified Border Element does not have any PDVM resources to terminate the SIP trunk assigned.
- B . The SIP provider expects a delayed offer.
- C . The SIP provider expects an early offer.
- D . The Cisco Unified Border Element must be licensed for third-party SIP trunks.
